SAMSUNG SRN-1673SP 16 Kanal PoE+ NVR Kayıt Cihazı

The black SRN-1673S 16-Channel Network Video Recorder with PoE Switch (1TB) from Samsung is a plug & play NVR with a built-in PoE/PoE+ network switch that allows cameras to be connected directly to the NVR, eliminating the need for additional hardware. The NVR is equipped with 4 front-accessible hard drives that provide 1TB of storage, thus allowing long-term recording. You can simply connect it to an HDMI/ VGA monitor and control it with a USB mouse/IR remote for easy setup and monitoring.

Up to 16-channel 8M supported

80 Mb/s network camera recording

Plug & play by 16 PoE/PoE+ ports

Maximum 4 HDDs, e-SATA storage supported

Removable HDD allows easy installation

HDMI / VGA local monitor

Video

Inputs Up to 16 channels

Resolution CIF to 8 MP

Protocols Samsung, ONVIF

Live View

Local Display HDMI / VGA

Multi-Screen Display Local monitor: 1 / 4 / 6 / 8 / 9 / 13 / 16 / Auto sequence

Web: 1 / 4 / 9 / 16 / Auto sequence

Frame Rate Local monitor 8 MP (20 fps), 5 MP (30 fps), 3 MP (50 fps), 2 MP (150 fps), 720p (240 fps), D1 (480 fps)

Web 5 MP (30 fps), 3 MP (60 fps), 2 MP (120 fps), 720p (240 fps), D1 (480 fps)

Performance

Operating System Embedded Linux

Recording

Compression H.264, MJPEG

Bandwidth 80 Mb/s (2 MP 16 camera real-time recording)

Mode Normal, Scheduled, Event (Pre / Post)

Event Trigger 8 x Alarm input, Video loss, Camera event (Alarm in, MD, Video analytics)

Event Action E-mail, PTZ preset, Alarm out, Buzzer, Monitor out

Search & Playback

Bandwidth 32 Mb/s

Users Maximum: 3

Mode Date & time (calendar) / Event log list / Text Search (POS)

Max Simultaneous Playback Local Monitor: Up to 16 channels

Web, CMS: Up to 16 channels

Resolution CIF to 8 MP

Fisheye Dewarp Mode Via Smartviewer

Playback Control Fast/Slow, Forward/Backward, Move one step up/down

Storage

Internal 2 SATA

External 1 e-SATA

Maximum Capacity Internal: 1 TB (included)

Backup

File Format USB: BU/Exe

Web, CMS: JPEG, AVI

Function Maximum 16 channel playback, Date-time/title display

Sensor

Input / Output 8 / 4 (3 x NO, 1 x NO/NC)

Audio

Input 8-channel (Network)

Compression G.711, G.726, AAC (16 / 48 kHz)

Audio Communication 2-way

Network

Protocol Support TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), PPPoE, SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S)

DDNS Samsung iPOLiS DDNS

Bandwidth Maximum 160 Mb/s (transmission)

Max. Remote Users Search: 3

Live Unicast: 10

Live Multicast: 20

IP IPv4 / IPv6

Security IP address filtering, User access log, 802.1x authentication, Encryption

GUI/Setup Menu Language English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch, Swedish, Czech, Portuguese, Danish, Rumanian, Serbian, Croatian, Hungarian, Greek, Norwegian, Finnish, Korean, Chinese, Japanese, Thai

OS Windows: XP SP2 and above, Vista, 7, 8,

Mac OS: OSX 10.6 and above

Web Browser Internet Explorer: Updated Version 8 to 10 (9 or above recommended)

Firefox: Version 19.x and above

Chrome: Version 26.x and above

Apple Safari: Version 6.0.3 and above

Viewer SSM, Webviewer, SmartViewer, iPOLiS mobile viewer

CMS Support: SDK / CGI (SUNAPI)

Setup and Configuration

Registration PnP mode, Manual mode

Functions IP address, Add Profile Edit, Bitrate, Compression, GOP, Quality, Camera MD setup, Camera video setup (Simple focus, Brightness / Contrast, Flip / Mirror, Iris, WDR, D&N, SSNR, Shutter, SSDR, DIS)

Camera Control PoE: Monitor PoE power consumption, On / Off control for each PoE camera, Remote reset for each PoE camera

Configuration Setup Wizard (Date / Time, Network, Auto camera configuration)

PTZ

Control Via GUI, Webviewer, SPC-2000

Presets 255

Smartphone

OS Support Android, iOS

Control Live: 4

Playback: 1

System Control Mouse, IR Remocon, Web, SPC-2000 (Controller)

Indicators

Front Panel Indicators 1 x Power status LED, 1 x HDD action LED, 1 x Alarm status LED, 1 x Record status LED, 1 x Network action LED, 1 x Back up LED

Interfaces / Ports

USB 2 (Front panel)

Display 1 x HDMI / VGA

Audio Out 1 x RCA, line

Network 8 x RJ45 (PoE/PoE+, 100 Mb/s)

1 x RJ45 (WAN, 1 Gb/s)

Alarm I/O 8 x Alarm in (terminal block)

4 x Alarm out (terminal block)

Reset Factory reset

System

Log Entries System Log: Maximum 20,000

Event Log: Maximum 20,000

Electrical

Input Voltage/Current 100 to 240 VAC / 6 to 3 A, 50/60 Hz

Power Consumption Maximum 309 W (4 HDD, PoE on), 57 W (2 HDD, PoE off)

PoE Budget Maximum: 200 W

Environmental

Operating Temperature 32 to 104°F (0 to 40°C)

Operating Humidity 20 to 85% RH

Mechanical

Material Metal

Dimensions (W x H x D) 17 x 3.5 x 15" (44 x 8.8 x 39 cm) (2U)

Weight Approximately 12.3 lb (5.60 kg), including 1 x 1 TB HDD

Packaging Info

Package Weight 17.15 lb

Box Dimensions (LxWxH) 21.18
