SAMSUNG SNP-6320RHP 2MP 32x IR IP SPEEDDOME KAMERA

• Max. 2M (1920 x 1080) resolution
• 16 : 9 Full HD (1080p) resolution support
• 4.4 ~ 140.8mm (32x) IR corrected optical zoom, 16x digital zoom
• H.264, MJPEG dual codec, Multiple streaming
• Day & Night (ICR), WDR (120dB)
• Auto tracking, Intelligent video analytics
• SD/SDHC/SDXC memory slot, Bi-directional audio support
• IP66, IK10, IR LED (2ea)

Video
Imaging Device 1/2.8" 2.38M CMOS
Total / Effective Pixels 1,952(H) x 1,116(V), 2.18M pixels / 1,944(H) x 1,104(V), 2.14M pixels
Scanning System Progressive
Min. Illumination
Color : 0.3Lux (1/30sec, F1.6, 50IRE), 0.005Lux (2sec, F1.6, 50IRE)
0.1Lux (1/30sec, F1.6, 30IRE), 0.0005Lux (2sec, F1.6, 30IRE)
B/W : 0Lux (IR LED on)
S / N Ratio 50dB
Video Output CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation
Lens
Focal Length (Zoom Ratio) 4.4 ~ 140.8mm (Optical 32x)
Max. Aperture Ratio F1.6(Wide) / F4.9(Tele)
Angular Field of View H : 63.68˚(Wide) ~ 2.24˚(Tele) / V : 37.52˚(Wide) ~ 1.28˚(Tele)
Min. Object Distance 1.5m (4.92ft)
Focus Control AF / One-shot AF / Manual
Lens / Mount Type DC auto iris (IR corrected) / Board-in type
Pan / Tilt / Rotate
Pan / Tilt Range 360˚ Endless / 190˚ (-5˚ ~185˚ )
Pan / Tilt Speed Preset : 250˚/sec, Manual : 0.024˚/sec ~ 120˚/sec
Sequence / Preset Accuracy Preset (255ea), Swing, Group (6ea), Trace, Tour, Auto run, Schedule / ±0.2˚
Azimuth Yes (E / W / S / N / NE / SE / NW / SW OSD)
Auto Tracking Off / On
Operational
IR LED 2ea
Viewable Length 150m (492.13ft)
Camera Title Off / On (Displayed up to 15 characters)
Day & Night Auto (ICR) / Color / B/W
Backlight Compensation Off / BLC / HLC / WDR
Wide Dynamic Range 120dB
Contrast Enhancement SSDR (Samsung Super Dynamic Range) (Off / On)
Digital Noise Reduction SSNRIII (2D+3D noise filter) (Off / On)
Digital Image Stabilization Off / On
Defog Off / Auto / Manual
Motion Detection Off / On (4ea, Rectanglular zones)
Privacy Masking Off / On (32ea, Rectanglular zones)
- Color : Grey / Green / Red / Blue / Black / White, - Zoom ratio option for mask mode
Gain Control Off / Low / Medium / High / Manual
White Balance ATW / AWC / Manual / Indoor / Outdoor / Mercury / Sodium
Electronic Shutter Speed Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec)
Digital Zoom 16x, area zoom funtion support digital zoom 2x
Flip / Mirror Off / On
Intelligent Video Analytics Tampering (Scene change), Virtual line, Enter / Exit, (Dis)Appear,
Audio detection, Face detection
Alarm I/O Input 4ea / Output 3ea (Relay type)
Remote Control Interface RS-485/422
RS-485 Protocol Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon, Bosch, GE
Alarm Triggers Alarm input, Motion detection, Intelligent video analytics, Network disconnect
Alarm Events File upload via FTP and E-mail, Notification via E-mail,
Local storage(SD/SDHC) or NAS recording at Network disconnected, External output, PTZ preset
Network
Ethernet RJ-45 (10/100BASE-T)
Video Compression Format H.264 (MPEG-4 Part 10/AVC) : Main / Baseline / High, MJPEG
Resolution 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768,
800 x 600, 720 x 576, 640 x 480, 640 x 360, 320 x 240, 320 x 180
Max. Framerate
H.264 : Max. 60fps at all resolutions
MJPEG : 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 : Max. 15fps
800 x 600, 720 x 576, 640 x 480, 640 x 360, 320 x 240, 320 x 180 : Max. 30fps
Smart Codec Manual mode (Area-based : 5ea), Face detection mode
Video Quality Adjustment H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control
Bitrate Control Method H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability Multiple streaming (Up to 10 profiles)
Audio In Selectable (Mic in / Line in), Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm
Audio Out Line out (3.5mm stereo mini jack), Max output level : 1 Vrms
Audio Compression Format G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz,
G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
Audio Communication Bi-directional audio (2-way)
IP IPv4, IPv6
Protocol TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP,
SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
Security HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication (EAP-TLS, EAP-LEAP)
Streaming Method Unicast / Multicast
Max. User Access 15 users at unicast mode
Edge Storage
SD/SDHC/SDXC (Up to 128G)
Motion Images recorded in the SD/SDHC/SDXC memory card can be downloaded
NAS (Network Attached Storage), Local PC for instant recording
Application Programming Interface ONVIF profile S, SUNAPI (HTTP API), SVNP 1.2, Samsung Techwin Open Platform
Webpage Language English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese,
Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Finnish, Norwegian
Web Viewer
Supported OS : Windows XP / VISTA / 7 / 8, MAC OS X 10.7
Supported Browser : Microsoft Internet Explorer (Ver.8 ~ 11), Mozilla Firefox (Ver. 9 ~ 19),
Google Chrome (Ver. 15 ~ 25), Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7)
* Mac OS X only
Central Management Software SmartViewer, SSM
Environmental
Operating Temperature / Humidity -50°C ~ +55°C (-58°F ~ +131°F) / Less than 90% RH
Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
Ingress Protection / Vandal Resistance IP66 / IK10
Electrical
Input Voltage / Current 24V AC only / 6A
Power Consumption Max. 30W (Heater off) / Max. 35W/90W (Heater off/on, IR on)
Mechanical
Color / Material Ivory / Aluminum
Dimensions (WxH) Ø248.0 x 399.5mm (Ø9.76" x 15.73")
Weight 7.1Kg (15.65 lb)
