SAMSUNG SCP-2273P Speeddome Kamera 1/4"S.HAD 27X 680TVL ICR 24VAC

Video
Imaging Device 1/4" Sony 960H Ex-view HAD CCD II
Total Pixels 1,020(H) x 508(V) 1,020(H) x 596(V)
Effective Pixels 976(H) x 494(V) 976(H) x 582(V)
Scanning System 2 : 1 Interlace
Synchronization Internal / Line lock
Frequency H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Horizontal Resolution Color : 680TV lines, B/W : 680TV lines
Min. Illumination Color : 0.2Lux@F1.6 (50IRE), 0.0004Lux (Sens-up, 512x)
B/W : 0.01Lux@F1.6 (50IRE), 0.00002Lux (Sens-up, 512x)
S / N Ratio 52dB (AGC off, Weight on)
Video Output CVBS : 1.0 Vp-p / 75Ω composite
Lens
Focal Length (Zoom Ratio) 3.5 ~ 94.5mm (Optical 27x)
Max. Aperture Ratio 1 : 1.6(Wide) ~ 2.9(Tele)
Angular Field of View H : 56.26°(Wide) ~ 2.24°(Tele) / V : 43.28°(Wide) ~ 1.67°(Tele)
Min. Object Distance 1.8m (5.91ft)
Focus Control Auto / Manual / One shot
Zoom Movement Speed 2.7sec (Wide to tele)
Pan / Tilt
Pan Range 360° Endless
Pan Speed Preset : 500°/sec, Manual : 0.024°/sec ~ 120°/sec (Proportional zoom ratio)
Tilt Range -5° ~ 185°
Tilt Speed Preset : 500°/sec, Manual : 0.024°/sec ~ 120°/sec (Proportional zoom ratio)
Preset 255
Preset Accuracy ±0.1°
Operational
On Screen Display English, Japanese, Spanish, French,
Portuguese, Korean
English, French, German, Spanish,
Italian, Chinese, Russian, Polish,
Czech,Turkish, Portuguese
Camera Title Off / On (Displayed 12 characters)
Day & Night Auto (ICR) / Color / B/W
Backlight Compensation Off / BLC / HLC
Contrast Enhancement SSDR (Off / On)
Digital Noise Reduction SSNRIII (Off / On)
Digital Image Stabilization Off / On
Motion Detection Off / On
Privacy Masking Off / On (8 programmable zones)
Sens-up (Frame Integration) 2x ~ 512x
Gain Control Off / Low / Medium / High / Manual
White Balance ATW / Outdoor / Indoor / Manual / AWC (1,700°K ~ 11,000°K) / Mercury
Electronic Shutter Speed 1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Digital Zoom Off / On (1x ~ 16x)
Digital Flip Off / On
Schedule Day / Time
Alarm 8 In 3 Out
Communication Coaxial control (SPC-300 compatible), RS-485/422
Protocol Coax : Pelco-C (Coaxitron)
RS-485/422 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon, AD, GE
Environmental
Operating Temperature / Humidity -10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH : SCP-2273
-50°C ~ +55°C (-58°F ~ +131°F) / Less than 90% RH : SCP-2273H
Ingress Protection IP66 grade (SCP-2273H only)
Electrical
Input Voltage / Current 24V AC ±10%
Power Consumption Max. 15W : SCP-2273, Max. 15W / 60W (Fan & heater on) : SCP-2273H
Mechanical
Color / Material Ivory / Plastic (Dome cover : Clear) : SCP-2273
Ivory / Aluminum, Plastic (Dome Cover : Clear) : SCP-2273H
Dimensions (WxH) Ø152.0 x 218.0mm (Ø5.98" x 8.58") : SCP-2273
Ø220.0 x 293.6mm (Ø8.66" x 11.56") : SCP-2273H
Weight 1.6Kg (3.53 lb) : SCP-2273, 3.1Kg (6.83 lb) : SCP-2273H
