SAMSUNG QND-7080RP 4MP 2.8~12mm Mot.Varifocal,PoE, IR IP DOME KAMERA

SAMSUNG QND-7080RP 4MP 2.8~12mm Mot.Varifocal,PoE, IR IP DOME KAMERA • Max. 4M resolution• 2.8 ~ 12mm (4.3x) motorized varifocal lens• Max. 20fps@4M, Max.30fps@2M all resolutions• H.265, H.264, MJPEG codec supported• Day & Night (ICR), WDR (120dB)• Motion detection, Tampering, Defocus detection• micro SD (128GB) memory slot, PoE / 12V DC• IR viewable length 20m• Hallway view support• LDC support (Lens Distortion Correction) VideoImaging Device 1/3" 4M CMOSTotal Pixels 2,720(H) x 1,536(V)Effective Pixels 2,688(H) x 1,520(V)Scanning System ProgressiveMin. Illumination Color : 0.15Lux (30IRE), B/W : 0Lux (IR LED on)LensFocal Length (Zoom Ratio) 2.8 ~ 12mm (4.3x) motorized varifocalMax. Aperture Ratio F1.4Angular Field of View H : 109.7˚ ~ 26.0˚ / V : 60.8˚ ~ 15.2˚ / D : 131.3˚ ~ 30.1˚Focus Control Simple focus (Motorized V/F) / Manual, Remote control via networkLens Type DC auto irisMount Type Board typePan / Tilt / RotatePan / Tilt / Rotate Range 0° ~ 350° / 0° ~ 67° / 0° ~ 355°OperationalIR Viewable Length 20m (65.62ft)Camera TitleOff / On (Displayed up to 20 characters per line)- W/W : English / Numeric / Special characters- China : English / Numeric / Special / Chinese characters- Common : Multi-line (Max. 5), Color (Grey / Green / Red / Blue / Black / White),Transparency, Auto scale by resolutionDay & Night True Day & NightBacklight Compensation Off / BLC / WDRWide Dynamic Range 120dBDigital Noise Reduction SSNR (Off / On)Motion Detection Off / On (4ea polygonal zones)Privacy Masking Off / On (6ea rectangular zones)Gain Control Off / Low / Middle / HighWhite Balance ATW / AWC / Manual / Indoor / OutdoorLDC (Lens Distortion Correction) Off / On (5 levels with min / max)Electronic Shutter Speed Minimum / Maximum / Anti flickerFlip / Mirror Flip / Mirror / Hallway viewIntelligent Video Analytics Motion detection with metadata, Tampering, Defocus detectionAlarm I/O Input 1 / Output 1Alarm Triggers Motion detection, Tampering detection, SD card error, NAS error,Alarm input, Defocus detectionAlarm Events File upload via FTP and E-mail, Local storage recording at event,Notification via E-mail, External outputPixel Counter Support (Plug-in viewer only)NetworkEthernet RJ-45 (10/100BASE-T)Video Compression Format H.265, H.264, MJPEGResolution 2592 x 1520, 2560 x1440 (16 : 9), 2304 x 1296, 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720,1024 x 768, 800 x 600, 800 x 450, 720 x 576, 720 x 480, 640 x 480, 640 x 360, 320 x 240Max. Framerate H.265/H.264 : Max. 20fps at 4M, Max. 30fps at 2M all resolutions, MJPEG : Max. 15fpsSmart Codec WiseStreamVideo Quality Adjustment H.265/H.264 : Target bitrate level control, MJPEG : Quality level controlBitrate Control Method H.265/H.264 : CBR or VBR, MJPEG : VBRStreaming Capability Multiple streaming (Up to 3 profiles)Audio I/O Built-in micAudio Compression Format G.711 u-law / G.726 selectableG.726 (ADPCM) 8KHz, G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40KbpsAudio Communication Uni-directional audioIP IPv4, IPv6Protocol TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP,SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, BonjourSecurity HTTPS(SSL) login authentication, Digest login authenticationIP address filtering, User access log, 802.1x authenticationStreaming Method Unicast / MulticastMax. User Access 6 users at unicast modeStoragemicro SD/SDHC/SDXC max. 128G, NAS- Motion images recorded in the SD memory card can be downloaded- Manual recording at local PCApplication Programming Interface ONVIF Profile S/G, SUNAPI (HTTP API)Webpage Language English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian,Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungary, GreekWeb ViewerSupported OS : Windows 7, 8.1, 10, Mac OS X 10.9, 10.10, 10.11Plug-in free Webviewer- Supported Browser : Google Chrome 47, MS Edge 20Plug-in Webviewer- Supported Browser : MS Explore 11, Mozilla Firefox 43, Apple Safari 9 * Mac OS X onlyCentral Management Software SmartViewerEnvironmentalOperating Temperature / Humidity -10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RHStorage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RHElectricalInput Voltage / Current PoE (IEEE802.3af, Class3) / 12V DCPower Consumption Max. 7.2W (PoE), Max. 6.4W (12V DC)MechanicalColor / Material Ivory / PlasticDimensions (WxH) Ø119.8 x 98.8mm (Ø4.72" x 3.89")Weight 355g (0.78 lb)
