Behringer SUPER-X PRO CX2310 Stereo 2 Yollu/Mono 3 Yollu Crossovers

Behringer SUPER-X PRO CX2310 Stereo 2 Yollu/Mono 3 Yollu Crossovers ve Subwoofer Çıkış

Ürün Özellikleri:

The CX2310 SUPER-X PRO from Behringer is an active frequency crossover enabling two-way stereo or three-way mono operation. Each band features two 24dB Linkwitz-Riley filters, as well as individual polarity switches for each output that allow for quick and easy runtime compensation for various driver and horn types.

Additionally, the CX2310 adds a separately adjustable subwoofer output that provides an extra low-frequency band. The unit is housed in a single rack space chassis and has illuminated switches for ease of use in dark environments.

Professional high-precision stereo 2-way or mono 3-way crossover
24dB per octave Linkwitz-Riley filters
Flat summed amplitude response, zero phase difference
Separate sub woofer section with independent frequency control
Individual output level controls for all bands
Individual output mutes for easy band adjustment and individual phase reverse switches for instant phase correction
Switchable 25Hz subsonic filter on each input for low-frequency driver protection
Adjustable time delay for phase alignment between drivers
Illuminated switches for secure operation in dark stage environments
Shielded toroidal mains transformer for minimal noise interference

Filter Type 24dB per octave Linkwitz-Riley, state-variable
Operating Modes Stereo 2-way, switchable to mono 3-way
Crossover Frequencies Stereo Mode Frequencies
Low/High: 44Hz to 930Hz (440 Hz to 9.3 kHz using x10 switch)
Mono Mode Frequencies
Low/Low-Mid: 44Hz to 930Hz (440 Hz to 9.3 kHz using x10 switch)
Low/High: 44Hz to 930Hz (440 Hz to 9.3 kHz using x10 switch)
High-Mid/High: 440Hz to 9.3kHz
Gain Range +/-6dB
Front Panel Switches Mute (individual per band)
Phase (individual per band)
Low cut (per side)
Inputs 2 x XLR
Outputs 5 x XLR
Maximum Input Level +22dBu typical, balanced or unbalanced
Maximum Output Level +20dBm, balanced or unbalanced
Frequency Response 5Hz to 60kHz, +/-3dB
Dynamic Range Not specified by manufacturer
Noise SNR: Between >91dBu and >95dBu, depending on configuration
Dimensions (WxDxH) 19" x 8 1/2" x 1 3/4"
Weight 6.6 lbs
Specialties 25Hz sub-sonic filter on each input for low-frequency driver protection
Packaging Info
Package Weight 6.7 lb
Box Dimensions (LxWxH) 20.7 x 12.3 x 4.3"
